Patz feed mixers 350, 620 and 950: 11.3 to 31.1 m³ behind tractors from 65 hp
The Patz 350, 620 and 950 are tractor-drawn vertical feed mixers that batch and deliver a total mixed ration from one tub. The 350 runs a single screw on a 65 hp tractor and suits a dairy, small feedlot, or backgrounding operation. The 620 and 950 run twin screws and are sized for feedlots putting out 7.2 to 11 tonnes of ration a batch.
DOM Distribution imports all three to Dalby, fits Digi-Star scales and the standard Patz feedout elevator before delivery, and services them from the same yard. You can buy, hire, or rent to buy.
What is a vertical feed mixer
A vertical feed mixer is a tub with one or more upright screws that lift feed from the floor, let it fall, and blend it into a total mixed ration (TMR). It handles round bales, silage, grain and supplements in one batch. A tractor-drawn model is towed and driven off the PTO, with scales so you weigh each ingredient in.
How the three Patz sizes compare
The difference between the three models is tub capacity, screw count and the tractor in front. The 350 heaps 11.3 m³ with one screw and needs 65 PTO hp. The 620 heaps 20.3 m³ with two screws and needs 85 PTO hp. The 950 heaps 31.1 m³ with two screws and needs 145 PTO hp. All three capacities come with standard feedout elevator fitted, a 3m custom elevator can be supplied and fitted by DOM on the 350 and 620.
Maximum ration load follows the same step: 4 tonnes on the 350, 7.2 tonnes on the 620, 11 tonnes on the 950. Those are the figures to size your batch against, not the tub volume, because a heavy grain ration reaches the load rating before it fills the tub.
Patz 350: single screw, 11.3 m³, 65 hp
The Patz 350 is the mixer for an operation with one mid-sized tractor and a ration that changes through the year. One Tru Taper screw with dual kicker turns in a tub 4.6 m long and 2.6 m wide, and you tow it on a single axle at PTO speed of 540 rpm. It heaps 11.3 m³ and carries up to 4 tonnes of ration a batch.
Australian units come with Digi-Star scales as standard and a 3 m elevator option, so you fill feeder bins and a bunk from the same load. Up to seven knives handle round bales.
Patz 620: twin screw, 20.3 m³, 85 hp
The Patz 620 is the step up to two screws for a small to medium feedlot or a dairy feeding twice a day. Two Tru Taper screws in a 7.3 m tub heap 20.3 m³ and carry 7.2 tonnes a batch behind a tractor with 80hp PTO. It sits on a dual axle with four 285/70R19.5 tyres at PTO speed of 1000 rpm, with a rear commodity door 762 mm high and 991 mm wide and up to 14 knives across both screws. Paired with DOM's 3 m elevator it feeds bins and bunk in one pass.
Patz 950: twin screw, 31.1 m³ for feedlots
The Patz 950 is the feedlot mixer. Two Tru Taper screws in an 8.4 m tub heap 31.1 m³ and carry 11 tonnes a batch behind a 145 PTO hp tractor, with Patz's patented Vortex mixing action moving the ration end to end. The 2026 build is the 2400 Series III: 8,677 kg empty, 19,450 kg gross, a four-point scale system, eight 245/70R19.5 tyres on a split dual or tandem walking beam, and a choice of two-speed manual or T2/T3 Autoshift transmission. The 950XH build takes the sidewalls from 6 mm to 9 mm and the screw flighting from 16 mm to 19 mm for high-hay and high-grain rations, and weighs 9,554 kg empty.
How big a feed mixer do you need
Divide the mixer's maximum ration load by your as-fed feed per head per feed. That gives head fed per batch. Multiply by the batches you can run in the feeding window and you have the herd size the mixer covers.
Worked on DOM's published load figures with an as-fed ration of 25 kg a head a day, fed once: the 350 covers about 160 head a batch, the 620 about 290, and the 950 about 440. Feed twice a day and each mixer covers roughly double. Your nutritionist's as-fed figure replaces the 25 kg, and the arithmetic stays the same.
Size to the ration you will feed in three years, not the one you feed now. A mixer running at 70 to 80 percent of its load rating mixes cleaner and wears slower than one running full every batch.
How much tractor does a feed mixer need
DOM's minimums are 65 PTO hp for the 350, 85 PTO hp for the 620 and 145 PTO hp for the 950. Those are continuous-run figures. Starting a full tub of round bales from rest needs more, which is why the 620 and 950 offer a two-speed gearbox: you start in low, shift up once the mix is moving, and take the torque spike off the tractor.
Single screw or twin screw
A single screw mixes well up to about 12 m³ and keeps the tractor requirement, tub length and price down. Past that, a second screw keeps the mix moving end to end in a longer tub, which is what the patented baffles in the 620 and 950 are shaped for. If your batch is under 4 tonnes, the single-screw 350 does the job. If it is over 4 tonnes, or you process a lot of round bales, twin screw. All three run Patz Tru Taper screws; the twin-screw tubs add the patented Vortex mixing action.
Specifications
| Model | Patz 350 | Patz 620 | Patz 950 |
|---|---|---|---|
| Series | 800 Series II | 1600 Series II | 2400 Series III |
| Screws | 1, Tru Taper | 2, Tru Taper | 2, Tru Taper |
| Heaped capacity, extension fitted | 11.3 m³ | 20.3 m³ | 31.1 m³ |
| Base tub capacity | 9.9 m³ | 17.6 m³ | 26.9 m³ |
| Max ration load(@400kg/m³) | 4 tonnes | 7.2 tonnes | 11 tonnes |
| Empty weight | 2,608 kg | 6,214 kg | 8,677 kg (XH 9,554 kg) |
| Max gross weight | 6,590 kg | 13,245 kg | 19,450 kg |
| Min PTO power, continuous | 65 hp | 85 hp | 145 hp |
| PTO speed | 540 rpm | 1000 rpm | 1000 rpm |
| Drive | Direct drive | Direct drive or two-speed | Two-speed manual or T2/T3 Autoshift |
| Overall length | 4.6 m | 7.3 m | 8.4 m |
| Overall width | 2.6 m | 2.6 m | 2.8 m |
| Overall height | 2.5 m | 2.6 m | 2.8 m |
| Axle / tyres | Single, 2 × 320/70R15 | Dual, 4 × 285/70R19.5 | Split dual or tandem walking beam, 8 × 245/70R19.5 |
| Scale system | 3 point, Digi-Star standard | 3 point, Digi-Star standard | 4 point, Digi-Star standard |
| Rear commodity door | 762 × 864 mm | 762 × 991 mm | 762 × 1,067 mm |
| Max knives | 7 | 14 (7 a screw) | 14 (7 a screw) |
| Sidewall / floor | 6 mm / 13 mm | 6 mm / 16 mm | 6 mm / 19 mm (XH 9 mm sidewall) |
Figures from the DOM Distribution product pages and brochures (950/950XH brochure dated 2026) and the Patz vertical mixer catalogue, checked September 2026. Load ratings at 25 lb/ft³ ration density. Ask us for the current build sheet before you order, as options change the weights.
What comes standard on Australian units
Every Patz mixer DOM delivers in Australia comes with Digi-Star scales fitted, so you weigh the ration in from day one. The 350 and 620 can take DOM's custom-fabricated 3 m elevator for feeder bin and bunk feeding off one load. Every machine carries a one-year manufacturing warranty and a five-year prorated power transmission warranty, and DOM's service team in Dalby backs it after delivery.
Buy, hire or rent to buy
All three models are available to hire, to rent to buy, or to buy outright with finance through DOM's partners. Hire suits a seasonal feeding program or a first season on a mixed ration before you commit to a size.
Where it fits
The 350 suits dairies to a few hundred milkers, small feedlots, backgrounders and any operation feeding once a day off a 65 to 100 hp tractor. The 620 suits a small to medium feedlot or a dairy feeding twice a day on a mixed ration. The 950 is for commercial feedlots batching 10 tonnes at a time, or compost operations processing green waste and litter. Above 31 m³, DOM also carries the Patz 1100 at 36.1 m³ and the triple screw Patz 3600 at 44.7 m³. All three models here tow on implement tyres and stand between 2.5 and 2.8 m high, so check your shed door before the truck arrives.
Availability
Get in touch to secure yours today. Call +61 7 4662 3511 or request a quote on the model page. Patz mixers are built in Wisconsin and ship containerised, and DOM fits scales, elevator and knives in Dalby before delivery.
Frequently asked questions
What size tractor do I need for a Patz feed mixer?
The Patz 350 needs 65 PTO hp continuous. The 620 needs 85 PTO hp. The 950 needs 145 PTO hp. Starting a full load of round bales from rest takes more than the continuous figure, so allow a margin above the minimum, or specify the two-speed gearbox on the 620 or 950 and start the mix in low.
How many cattle can a Patz 950 feed?
The 950 carries 11 tonnes of ration a batch. At an as-fed intake of 25 kg a head a day, one batch feeds about 440 head once a day, or 220 head twice a day. Divide 11,000 by your own as-fed figure to get the number for your ration.
What is the difference between the Patz 620 and the 950?
The 950 heaps 31.1 m³ against 20.3 m³ on the 620, carries 11 tonnes against 7.2, and needs 145 PTO hp against 85. The 950 is 8.4 m long on eight tyres with a four-point scale; the 620 is 7.3 m on four tyres with a three-point scale. Both run twin screws.
Do Patz feed mixers come with scales in Australia?
Yes. Every Patz mixer sold by DOM Distribution in Australia is delivered with Digi-Star scales fitted as standard, so you weigh each ingredient into the tub and track daily ration and feed distribution.
Can a Patz mixer process round bales?
Yes. All three models take knives capable of chopping: up to 7 on the 350 and up to 14 on the 620 and 950. Patented Raptor knives face forward and cut down into the bale core. A multi-angle screw top directs the bale into the tub, and reversible restrictors speed up processing of long hay.
Can I hire a Patz feed mixer?
Yes. DOM Distribution hires the Patz 350, 620 and 950 from Dalby, Queensland, and offers rent to buy on all three. Hire units are the same Australian-spec machines as the ones we sell.
See the full Patz tractor-drawn range and request a quote on the model page, or call DOM Distribution on +61 7 4662 3511 and we will size a Patz to your ration, your tractor and your feeding window.
